Non Valved 2 Inch Stainless Steel Quick Release Couplings

Product Categories
Phidix Motion Controls (Shanghai) Co., Ltd.
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

Non Valved 2 Inch Stainless Steel Quick Release Couplings

  • 1
  • 2

Brand Name : carterberg

Model Number : CB-11

Certification : IATF16949

Place of Origin : Shanghai, China

MOQ : Negotiation

Price : Negotiation

Payment Terms : L/C, D/A, D/P, T/T, Western Union

Supply Ability : 5000~20000 pc/month

Delivery Time : 7-20 work days

Packaging Details : carton

Material : Brass,stainless steel

Color : Yellow

Connection : Female

Name : Quick Connector

Application : Water pipe system

Size : Customized Size

Rated flow : 3 to 100

Compatible with : PARKER ST Series, HANSEN ST Series, FOSTER FST Series

Contact Now

Non-Valved Series maximum flow straight-through couplings

CB-11 Series straight-through couplings are designed for use where minimum pressure drop is required and valving is not needed. They are well suited for use on pressure wash, steam cleaning and carpet cleaning equipment, and many fluid transfer systems. Body sizes range from 1/8" to 1".

Standard Materials

  • Brass, zinc-plated steel, stainless steel
  • Seals: NBR, Viton, EPDM

Features

  1. Ball lock
  2. Manual operation
  3. Smooth bore permits free flow of liquid or gas
  4. Male and female NPTF, BSPP and hose stem connections
  5. Compatible with PARKER ST Series, HANSEN ST Series, FOSTER FST Series.
BODY SIZE Rated Pressure (PSI) Rated Pressure (BAR) Standard seal material
1/8" 2800 193 NBR
1/4" 5200 359
3/8" 2800 193
1/2" 2200 152
3/4" 1700 117
1" 1300 90

Non Valved 2 Inch Stainless Steel Quick Release Couplings

Body Size PARTNO. Brass PARTNO. Stainless Thread A B HEX
1/8" CB-S1B-11FN CB-S1L-11FN 1/8-27 1.06 0.69 0.50
1/8" CB-S1B-11FG CB-S1L-11FG 1/8-28 1.03 0.69 0.56
1/4" CB-S2B-11FN CB-S2L-11FN 1/4-18 1.50 0.94 0.81
1/4" CB-S2B-11FG CB-S2L-11FG 1/4-19 1.50 0.94 0.81
3/8" CB-S3B-11FN CB-S3L-11FN 3/8-18 1.59 1.13 1.00
3/8" CB-S3B-11FG CB-S3L-11FG 3/8-19 1.59 1.13 1.00
1/2" CB-S4B-11FN CB-S4L-11FN 1/2-14 1.91 1.31 1.13
1/2" CB-S4B-11FG CB-S4L-11FG 1/2-14 1.91 1.31 1.13
3/4" CB-S6B-11FN CB-S6L-11FN 3/4-14 2.06 1.69 1.44
3/4" CB-S6B-11FG CB-S6L-11FG 3/4-14 2.06 1.69 1.44
1" CB-S8B-11FN CB-S8L-11FN 1-11 2.31 2.00 1.75
1" CB-S8B-11FG CB-S8L-11FG 1-11 2.33 2.00 1.75

Non Valved 2 Inch Stainless Steel Quick Release Couplings

Body Size PARTNO. Brass PARTNO. Steel PARTNO. Stainless Thread C D HEX
1/8" CB-P1B-11FN CB-P1S-11FN CB-P1L-11FN 1/8-27 1.00 0.58 0.50
1/8" CB-P1B-11FG CB-P1S-11FG CB-P1L-11FG 1/8-28 0.97 0.65 0.56
1/4" CB-P2B-11FN CB-P2S-11FN CB-P2L-11FN 1/4-18 1.50 0.79 0.69
1/4" CB-P2B-11FG CB-P2S-11FG CB-P2L-11FG 1/4-19 1.45 0.87 0.75
3/8" CB-P3B-11FN CB-P3S-11FN CB-P3L-11FN 3/8-18 1.63 0.94 0.81
3/8" CB-P3B-11FG CB-P3S-11FG CB-P3L-11FG 3/8-19 1.63 1.01 0.88
1/2" CB-P4B-11FN CB-P4S-11FN CB-P4L-11FN 1/2-14 1.94 1.15 1.00
1/2" CB-P4B-11FG CB-P4S-11FG CB-P4L-11FG 1/2-14 1.92 1.23 1.06
3/4" CB-P6B-11FN CB-P6S-11FN CB-P6L-11FN 3/4-14 2.06 1.37 1.19
3/4" CB-P6B-11FG CB-P6S-11FG CB-P6L-11FG 3/4-14 2.01 1.52 1.31
1" CB-P8B-11FN CB-P8S-11FN CB-P8L-11FN 1-11 2.21 1.80 1.56
1" CB-P8B-11FG CB-P8S-11FG CB-P8L-11FG 1-11 2.23 1.80 1.56

Our Services:

1. Customized design, OEM is available.
2. In-time & professional after sales service.
3. Low MOQ, standard package, fast delivery.
4. Special discount and protection are provided to our distributors.
5. As an honest seller, we always use superior raw material, advanced equipments, skilled technicians and strict quality control to ensure our products to be finished in high quality and stable feature.


Product Tags:

2in Stainless Steel Quick Release Couplings



IATF 16949 Stainless Steel Quick Release Couplings



NBR hydraulic quick coupler


Quality Non Valved 2 Inch Stainless Steel Quick Release Couplings wholesale
